Ultra High Efficiency ASME & Non-ASME eF Series

The eF Series® utilizes exclusive designs and technologies for unsurpassed efficiency, installation flexibility and quiet operation. With thermal efficiencies as high as 99.1% these units are the most efficient of their kind in the industry. Complies with SCAQMD Low NOx requirements

Bradford White's eF Series^® Efficiency Calculator makes it easy to see the savings!
http://bradfordwhite.com/efcalculator.asp

ECO-Defender Safety System Ultra Series water heaters from Bradford White emit 75% less NOx emissions than standard models while maintaining optimal combustion efficiencies.

ECO DEFENDER SELL SHEET

ECO DEFENDER SPEC SHEET

ECO DEFEDER HIGH EFECIENCY SPEC

GO SOLAR

Bradford White offers two solar water heaters. When going the solar rout, take a look at Bradford White’s Solar Saver or Solar Stor with heat exchanger.

SOLAR SAVER SPEC SHEET

SOLAR STOR SPEC SHEET

High Efficiency Electric

The High Efficiency electric water heater offers exceptional energy efficiency and low operating cost. Customers will appreciate the long-term savings they get from this efficient model.

HIGH EFFECIENCY ELECTRIC SPEC SHEET

ELECTRIC SELL SHEET

ENERGY FACTOR

Energy Factor (EF) is an overall efficiency rating of the water heater. The higher the EF, the more efficient the model. Water heaters with high EF ratings may cost more initially but save energy and money in the long run. Eventually, they will pay for themselves through a lifetime of energy savings.

Water heaters listed in the energy factor ratings include:

Electric storage water heaters with energy input ratings of 12 kilowatts or less and with a storage capacity of not less than 20 gallons no more than 120 gallons

Gas storage water heaters with energy input ratings of 75,000 Btu's per hour or less and with a storage capacity of not less than 20 gallons nor more than 100 gallons

Gas instantaneous water heaters with input ratings greater than 50,000 Btu's per hour but less than 200,000 Btu's per hour designed to deliver water at a controlled temperature of less than 180?°F

First Hour Rating

Another important factor in choosing a water heater, the 1st Hour Rating is an indicator of how much hot water a particular model can provide. The rating, in gallons of usable (desired temperature) hot water is reached by combining the amount of usable hot water stored in the tank plus how many gallons of usable hot water the water heater can generate in one hour of operation. For example, if a 40-gallon natural gas water heater will store 31 gallons of usable hot water and can deliver 41 gallons of usable hot water in the first hour, it’s 1st Hour Rating is 72 gallons. 1st Hour Ratings are included in the Energy Factor charts.

National Average Energy Costs

Information supplied by The Gas Appliance Manufacturers' Association and Bradford White

The Energy Factor Chart is subject to change without notice in accordance with our policy of continuous improvement.

The ratings documented on this chart are also listed at www.gamanet.org

CLICK FOR ELECTRIC ENERGY FACTOR

CLICK FOR NATURAL GAS ENERGY FACTOR

CLICK FOR PROPANE ENERGY FACTOR
